Punjab Junior Draftsman Post Question Paper

1. Depth of foundation for any structure is determined by:
A) Ranson’s formula
B) Reynolds formula
C) Roosevelt’s formula
D) Rankine’s formula

Related : Punjab State Civil Supplies Corporation Deputy/ District Manager Question Paper & Answer Key : www.pdfquestion.in/7268.html

2. In surveying, Theodolite is used for which of the following recording purposes?:
A) Linear measurement
B) Angular measurement
C) Magnetic meridian
D) Magnetic dip

3. In a simply supported beam of 10 m span having udl of 8 kN/m, the maximum Bending Moment shall be:
A) 80 kN/m
B) 100 kN/m
C) 0.8 kN/m
D) 10 kN/m

4. Which is the most water-efficient irrigation system?:
A) Surface
B) Flood
C) Drip
D) Sprinkler

5. Which type of foundation is preferred in places where heavy concentrated loads are to be distributed over the whole floor area?:
A) Spread
B) Stepped
C) Pile
D) Raft

6. Bearing Capacity of soil is defined as:
A) Maximum load / Unit depth
B) Maximum load / Unit area
C) Minimum load / Unit depth
D) Minimum load / Unit area

7. Building bye-laws of local municipal authorities govern which of the following?:
A) Quality of construction
B) Time period of construction
C) Rate of construction
D) Front and Rear setbacks

8. The correct sequence of stages for survey in highway alignment is:
A) Map study, Preliminary Survey, Reconnaissance and Detailed Survey
B) Preliminary Survey, Map Study, Reconnaissance and Detailed Survey
C) Reconnaissance, Map Study, Preliminary Survey and Detailed Survey
D) Map study, Reconnaissance, Preliminary Survey and Detailed Survey

9. Which of the following climates is most suitable for providing a courtyard in a building?:
A) Warm and Humid
B) Hot and Dry
C) Cold and Humid
D) Coastal

10. The surface course of flexible pavements is generally made of:
A) Hot mix molybdenum
B) Hot mix concrete
C) Hot mix asphalt
D) Hot mix moorum

11. What shall be the quantity of masonry required for a wall of 1 m x 2 m x 0.3 m?:
A) 0.2 cubic m
B) 0.6 cubic m
C) 600 cubic m
D) 0.06 cubic m

12. Safe Bearing Capacity is equal to:
A) Ultimate Bearing Capacity / Factor of Safety
B) Ultimate Bearing Capacity x Factor of Safety
C) Factor of Safety / Ultimate Bearing Capacity
D) Ultimate Bearing Capacity x 2

13. If the forces in the members of a structure as well as the reactions can be found by the conditions of equilibrium, then it is known as:
A) Statically stable
B) Statically unstable
C) Statically determinate
D) Statically indeterminate

14. What shall be the cost of construction of a building with 300 sq.m of plinth area having plinth area rate of Rs. 15,000 per sq.m?:
A) Rs. 25 lakhs
B) Rs. 35 lakhs
C) Rs. 45 lakhs
D) Rs. 55 lakhs

15. Which type of masonry uses well-dressed stones with sharp, straight and smooth faces?:
A) Ashlar
B) Random
C) Rubble
D) Squared

16. Excavation of soil for foundation is measured in
A) Metre
B) Square metre
C) Cubic metre
D) Lump sum

17. The property by virtue of which a deformed body springs back to its original position after removing the external force is known as
A) Plasticity
B) Elasticity
C) Ductility
D) Tenacity

18. In PCC (Plain Cement Concrete) of ratio 1:2:4, the ratios stand for which of the following?
A) Water : Cement : Fine aggregate
B) Fine aggregate : Coarse aggregate : Cement
C) Cement : Fine aggregate : Coarse aggregate
D) Cement : Coarse aggregate : Fine aggregate

19. What is the main ingredient in ordinary portland cement?
A) Alumina
B) Gypsum
C) Silica
D) Lime

20. Floor area ratio as per National Building Code is
A) Total built up area / Plot area
B) Plot area / Total built up area
C) Total ground floor area / Plot area
D) Ground floor area / Total built up area

21. Which of the following defines the Slenderness Ratio of a steel column?
A) Effective length of column / least width of column
B) Effective length of column / net load on column
C) Effective length of column / least radius of gyration
D) Effective length of column / moment of inertia

22. Which of the following instruments is used in plane table survey?
A) Dumpy level
B) Tilting level
C) Alidade
D) Vernier scale

23. In an under reinforced section, the depth of actual neutral axis is
A) less than the maximum depth of neutral axis or Xu < Xumax
B) more than the maximum depth of neutral axis or Xu > Xumax
C) equal to the maximum depth of neutral axis or Xu = Xumax
D) equal to the half of depth of beam or Xu = d/2

24. Contour lines in a map are the lines connecting points having
A) Same elevation
B) Same angle
C) Same curve
D) Same distance

25. Which of the following devices is used to measure fluid pressure?
A) Manometer
B) Liquid Meter
C) Nanometer
D) Hydrometer
