ME010803 Production Engineering B.Tech Model Question Paper : mgu.ac.in

Name of the College : Mahatma gandhi University
Department : Mechanical Engineering
Subject Code/Name : ME 010 803/Production Engineering
Sem : VIII
Website : mgu.ac.in
Document Type : Model Question Paper

Download Model/Sample Question Paper : https://www.pdfquestion.in/uploads/mgu.ac.in/4987-ME%20010%20803.pdf

MGU Production Engineering Model Question Paper

Branch: Mechanical Engineering
Production Engineering [ME 010 803]
Time: 3 hrs

Related : MGU ME010805G01 Industrial Safety B.Tech Model Question Paper : www.pdfquestion.in/4988.html

Maximum marks: 100
Part A :
Answer all questions : (3×5 marks)
1. Differentiate two dimensional and three dimensional cutting.
2. List the factors that affect machinability.
3. What are the applications of Diamond turn mechanism?
4. Effect of fibre length on composites?
5. What are the process parameters of EDM?

Part B :
Answer all questions : (5×5 marks)
6. What are the conditions which will favour the formation of continuous chips?
7. What are the functions and properties of cutting fluids? Explain.
8. Explain MRAFF process
9. What are the imperfections in ceramics?
10. What are the different processes in rapid prototyping

Part C :
Each question carries 12 marks :
11. With the help of figures explain the nomenclature of single point cutting tool.
Or
12. What is merchant circle? Explain its uses.

13. Explain the type of tool materials and discuss their applications
Or
14. Discuss Taylor’s relationship for cutting speed – tool life. What are the factors affecting tool life and how can it be improved? What is the effect of cold working in machinability?

15. What are the design considerations in powder metallurgy? Also discuss the powder properties of powder used in powder metallurgy
Or
16. Explain the manufacturing of powder metallurgy components with the help of a flow chart.

17. Classify ceramic materials. Discuss the steps of processing of ceramics
Or
18. Discuss about AmXp, AmBmXp type crystal structures

19. With a neat sketch explain Electrochemical machining process? List the major process parameters and applications.
Or
20. Explain
I. Liga process
II. Fused deposition modelling
III. Abrasive water jet machining

May 2014

B.Tech. Degree Examination,
Eighth Semester :
Branch : Mechanical Engineering
Design Of Transmission Elements (M) : (Regular/Supplementary)
Time : Three Hours
Maximum Marks : 100
Answer one full question from each module
Use of Design Data Book is permitted. .
Missing Data may be assumed.

Syllabus

Module-1 :
1. A cone clutch has a cone angle of 300 and is used to transmit 10 kW at 1500rpm. The width of the face is one-fourth of the mean diameter of friction lining. The normal intensity of pressure between contact surfaces is 0.12 MPa and coefficient of friction is 0.2, assuming uniform wear, design the clutch dimensions. (25 marks)
OR

2. A differential band brake has an operating lever 240mm long. The ends of the band are attached at 40mm and 120mm on either side of the pivot. The drum diameter is 600mm. Arc of contact is 3000. Design the brake to absorb 15kWat 1200 rpm. (25 marks)

Module-2 :
3. (a)What is the difference between thick film and thin film lubrication?
(b)The following data is given for a 360° hydrodynamic bearing,
Radial load = 3.6 kN
Journal diameter = 55 mm
Bearing length = 27.5 mm
Radial clearance = 0.05 mm
Viscosity of lubricant = 25 CP.
Somerfield number of bearing is 0.0923.
Determine (i) Journal speed; (ii) Coefficient of friction; (iii) Power loss in friction; (iv) Flow requirement; (v) Temperature rise. (20 marks)
OR

4. A journal bearing 160 mm long and 45 mm dia. supports a radial load of 8,000 N. The shaft speed is 160 rpm; oil used is SAE 60 at 25° C inlet temperature. Using clearance ratio 600, find the rise in temperature, maximum films pressure and minimum film thickness. (25 marks)

Module-3 :
5. (a) How do you specify the size of gear tooth? (5 marks)
(b) A pair of spur gear is to be designed. The pinion rotates at 800 rpm. and transmits 6 kW to gear rotating at 200 rpm; Starting torque can be taken as 140% of rated torque for pinion and gear allowable stress is 150 MPa. (20 marks) .
OR

6. (a) Explain why helical gears are capable of transmitting, grater power at high speed as compared to the spur gear. (5 marks)

(b) A pair of helical gears is to be designed to transmit 20 KW at a pinion speed of 1500 rpm. The velocity ratio is 2.5. Selecting suitable materials, determine the dimensions of the gears. (20 marks)

Module-4 :
7. Design a flywheel for a single cylinder, four stroke vertical cylinder diesel engine developing 4kW at 1500 rpm. Assume coefficient of speed fluctuation Cs=0.01. (25 marks)
