South East Central Railway Junior Engineer Question Paper

Total marks: 100
Time: 2 hrs.

1. Rail with rolling mark 60 880 SAIL 0 XI / 2024 indicates _________ grade rail.
a) 60
b) 880
c) 0
d) 2024

2. IMR defective rails shall be replaced within _______ days.
a) 1
b) 3
c) 15
d) 30

3. DFWR welds secured with joggled fish plates and clamps shall be replaced within _____ days.
a) 3 days
b) 15 days
c) 3 months
d) 6 months

4. Maximum degree of BG curve is _______.
a) 15
b) 10
c) 5
d) 8

5. Virtual transition length on BG is _______m
a) 14.6
b) 13.7
c) 20
d) 11.2

6. The census of traffic at all level crossings is taken once in ___ years.
a) 1
b) 3
c) 5
d) 7

7. Speed indicator will be erected at a height of _______ m from rail level
a) 1.65 m
b) 2.5 m
c) 2 m
d) 3 m

8. Sleeper density of 1660 nos./km has a sleeper spacing of _________ cm.
a) 55
b) 60
c) 65
d) 70

9. Radius of a 5˚ curve is-
a) 1750
b) 875
c) 350
d) 550

10. Full form of DMTR
a) Detonator Material Transaction Register
b) Dead Material Transaction Register
c) Daily Material Transaction Register
d) None of these.

11. Chord length for measuring lead curvature of a turn-out is
a) 3 m
b) 4m
c) 6m
d) 9m

12. Formation cross slope shall be 1 in ………
a)10
b) 20
c) 30
d) 40

13. Degree of a curve of radius 1750 m ?
a) 1.25°
b) 1°
c) 2°
d) 0.5°

14. Degree of a curve of radius 875m ?
a) 1.25°
b) 1°
c) 2°
d) 0.5°

15. Dynamic gauge for BG
a)1750 mm
b) 1776 mm
c)1676 mm
d) 1057 mm

16. USFD test is done for
a) Rail
b) Weld
c) both (a) & (b)
d) None of the above

17. What is the height of 60 kg rail section?
a) 180 mm
b) 172 mm
c) 185 mm
d) 165 mm

18. What is the full form UTS of rails
a) Ultimate technical Strength
b) Ultimate tensile Strength
c) Upper Top surface
d) None of above

19. Tilting of rail head is done at a slope of
a) 1 in 30
b) 1 in 25
c) 1 in 20
d) 1 in 15

20. Transition curve is situated at ————- of curve.
a) Both ends
b) At Centre
c) Anywhere
d) After tangent point

21. TVU is abbreviated for
a) Track vulnerable unit
b) Train vehicle Unit
c) Total vehicle unit
d) None of the above

22. Formation width on curve
a) Increases
b) decreases
c) remain the same
d) none of these

23. In through packing, ballast should be opened out on either side of rail seat to a depth of
a) 15 mm
b) 25 mm
c) 35 mm
d) 50 mm

24. Full form of TFR
a) Through Fitting renewal
b) Total Fitting renewal
c) Timely Fitting renewal
d) none of the above

25. During protection detonators are placed at what distance apart.
a) 5 m
b) 15 m
c) 10 m
d) 8 m

General Instructions for Candidates

General instructions as under:-
i) Candidates should not write his Name/Roll No. anywhere in the Answer sheet.
ii) Use of unfair means will lead to cancellation of candidature.
iii) Any extra question attempt will not be evaluated.
iv) Cutting, overwriting, erasing or alternation of any type in the answer will not be accepted. Zero marks will be given for answer having correction/overwriting.
v). There is no negative marking for incorrect answer.
vi) The question paper consists of 110 multiple choice questions out of which candidate has to attempt any 100 questions. Rajbhasha Question no. is from Q.No. 101 to 110 which is optional.
vii) All questions carry equal marks.
viii) During the examination Mobiles should be in switched off mode & calculators are not allowed.
